Construction:

Tube: CSM/EPDM Barrier-Nylon alloy Buffer-EPDM/NBR

Reinforcement: PVA

Cover: EPDM


Application: Applicable for Car,truck and passenger coach air conditioner systems to transfer environmentally friendly R134a and R12 refrigerant. SAE J2064 Type C #6, #8, #10, #12 Auto R134a refrigerant air conditioning line assembly with PA barrier thick / thin wall.


Characteristic:

● Refrigerant moisture ingression and heat resistance, excellent whip test resistance and noise reduction

● Aging resistance,Ozone resistance, Low permeability,Flexible

● Special tube compound resistant to high compression for coupling integrity.


Temperature: -40 ℉ to +250 ℉ (-40℃ to +121℃)
